Four Seasons 83294 A/C Refrigerant Suction Hose in Canada

Buyer fitment guide only intended as reference. Please use catalogue search by vehicle to ensure proper fitment.

Our accumulator / filter driers feature quality welds for a durable, leak-free design in addition to high-quality desiccant for appropriate absorption. For easy installation, necessary gaskets, o-rings and seal are included as well.
Replacement of the accumulator / filter drier is required to validate compressor warranty and must be replaced anytime the system is serviced.
The absorption of moisture in the system is done through the use of a desiccant bag. A leaking or "open" system can cause the bag to become saturated within a few hours making the accumulator/filter drier ineffective.
The accumulator / filter drier acts as a filter by removing moisture and contaminants from the air conditioning system. Such contaminants cannot be removed by flushing, therefore replacing the accumulator / filter drier is essential.
Our products are engineered and tested to provide years of trouble free operation. Backed by over 50 years of mobile a/c experience, fix it once and fix it right with Four Seasons.
As a manufacturer in accumulator/filter driers, we offer quality units produced in a ISO/TS16949 & ISO14001 certified facility. State-of-the-art equipment and high quality materials ensure product integrity for long lasting performance.

Other Names: A/C Accumulator with Hose Assembly, A/C Refrigerant Suction Hose

Material	Steel
Type	w/ Hose
Inlet Type	Female O-ring
Outlet Type	Male Springlock
California Proposition 65	WARNING: This product contains a chemical known to the State of California to cause cancer and birth defects or other reproductive harm.
Style	Suction Side
Inlet Gender	Female
Outlet Size	No. 12
Description	Accumulator w/ Hose Assy
O-Ring A Number/Desc	24650 / Green O-Ring
O-Ring B Number/Desc	24222 / Spring
O-Ring A Quantity	1
O-Ring B Quantity	1
O-Ring C Quantity	3
O-Ring C Number/Desc	24672 / Green O-Ring
Service Port?	w/ Service Port
Switch Port?	w/ Switch Port
Service Port Type	R134a Quick Disconnect
Meets / Exceeds OEM?	Yes
Length MM	280
Outlet MM	19.05
Outlet Fraction	3/4
Dia. MM	89
O-Ring D Number/Desc	24610 / Green O-Ring
Inlet IN	0.625
O-Ring D Quantity	1
Inlet MM	15.88
Outlet IN	0.750
Inlet Fraction	5/8
Suction End Type	Female O-ring
Manifold?	w/o Manifold
Muffler?	w/o Muffler
Bracket?	W/ Bracket
Dia. IN	3.500
Length IN	11
Switch Port Quantity	1
Service Port Qty	1
Sve Port Low Side	Low Side
Switch Gender	Male
UPC	00096361094444
Origin Country:	CN
Weight:	5.06Lb. (2.3 kg.)
Package Dimensions:	19.3" x 11.3" x 8.5" (48.9 cm x 28.6 cm x 21.6 cm)

1 Year Warranty

Four Seasons 83294 A/C Refrigerant Suction Hose
